Normally closed nc contacts allow current through when the relay or contactor is not energized.

Normally open auxiliary contact symbol. No terminal nc terminal and com terminal represent contact terminals symbols. Available in svg png. We can tell this switch is a normally open no switch because it is drawn in an open position. Auxilliary contacts symbols for use in electrical pneumatic and hydraulic schematic diagrams.

Auxiliary contact 1nc 1no. This is also called a changeover device because the common contact changes from the normally closed position to the normally open position when the coil is energized in a relay or a magnetic field is nearby in a reed switch. It consists of a coil and a number of auxiliary normally open or normally closed contacts. Normally open terminal normally closed terminal and common terminal respectively.

Jic nfpa sample drawing. Each symbol means a single terminal itself. Auxiliary contact 1nc 1no. When voltage is applied this contact opens and interrupts current.

These are contacts of relays contactors timers counter field instrument switches pressure switches limit switches etc. These terminals are usually labelled as normally open common and normally closed no c nc. These are known as normally closed n c and normally open n o contacts. There is a common electrical connection between a contact of each pair that results in only three connection terminals.

In other words when voltage is applied to the relay contactor terminals this contact closes. A form c would have 3 leads and would have 1 normally open and 1 normally closed circuit. Normally open contact iec symbols. There are two basic auxiliary contact types.

There are two types of contacts no normally open and nc normally closed. Normally open no contacts allow current when the relay or contactor is energized. Those that are closed in the non activated state or those that are open. On the other hand contact point a contact point b and contact point c represent contact structures.

The n c contacts are for example used as electrical interlocks where two contactors are used for forward reverse operation. Output coil can be auxiliary contactor or main contactor coil. Form c contacts change over or transfer contacts are composed of a normally closed contact pair and a normally open contact pair that are operated by the same device. A limiting condition is wired through the coil contacts and resulting conditions are wired through the.
